Specifications | Accuracy |
---|---|
Rated Capacity(R.O.) | 3kgf, 10kgf,20kgf,25kgf,50kgf |
Rated Output(R.O.) | 2mV/V±10% |
Nonlinearity | 0.02% R.O. |
Hysteresis | 0.02% R.O. |
Repeatability | 0.02% R.O. |
Creep | 0.03% R.O. |
Zer Balance | ±5% R.O. |
Terminal resistance input | 420±20Ω |
Terminal resistance output | 350±2Ω |
Insulation resistance bridge | 2000㏁ |
Temperature effect on rated output | 0.02% load / 10℃ |
Temperature effect on zero balance | 0.05% R.O. / 10℃ |
Temperature range, compensated | -10℃~50℃ |
Temperature range, safe | -10℃~50℃ |
Excitation recommended | 10V |
Safe Overload | 150% R.C |
Resistance, Input | 350Ω±3.5 |
Cable length | Φ3 4Core, 40㎝ |
Wiring information | EXC+ : Red, EXC- : White, SIG- : Green |
