CB122

This strain gage load cell has developed newly as a electronic "Scale" for commercial purpose, with the charatestics of high accuracy and low price.

Compared with another mechnical means, this load cell provides small displacement.

Due to electronic output, it is easy to treat various treatments.

WP Editor :

This strain gage load cell has developed newly as a electronic "Scale" for commercial purpose, with the charatestics of high accuracy and low price.

Compared with another mechnical means, this load cell provides small displacement.

Due to electronic output, it is easy to treat various treatments.

myfile

Specifications	Accuracy
Model	CB122
Rated capacity(R.C)	200gf, 300gf
Rated output(R.O)	1.2mV/V ± 20%
Nonlinearity	0.02% of R.O.
Hysteresis	0.02% of R.O.
Repeatability	0.02% of R.O.
Zero Balance	±5% of R.O.
Temperature range, compensated	0 ~ 40℃
Temperature range, safe	-10 ~ 50℃
Temp. Effect on rated output	±0.02% of LOAD/10℃
Temp. Effect on zero balance	±0.03% of R.O./10℃
Terminal resistance input	420 ± 30Ω
Terminal resistance output	350 ± 5Ω
Insulation resistance bridge	2000MΩ
Cable length	Φ3, 4CORE SHIELD CABLE, 1.5m
Excitation recommended	10V
Safe overload	150% R.C

★Specifications are subiect to change without notice.
