| DN5600 Application | Relay Mode |
 |
 |
|
General Specification |
|
|
Input Sensitivity |
0.2㎶ / Digit |
|
Load Cell Excitation |
DC 10V ( - 5V ~ + 5V ) |
|
Max. Signal Input Voltage |
Max.32mV |
|
Temperature Coefficient |
[Zero] ±20PPM/℃ / [Span] ±20PPM/℃ |
|
Input Noise |
±0.6㎶ P.P |
|
Input Impedance |
Over 10㏁ |
|
A/D Conversion Method |
Sigma-Delta |
|
A/D Resolution(Internal) |
520,000 Count(19bit) |
|
A/D Sampling Rate |
Max. 200times / Sec |
|
Non-Linearity |
0.01% FS |
|
Display Resolution(External) |
1/30,000 |
|
Display Part |
||
|
Display |
Parts |
Specification |
|
Display |
Main Display |
7Segments, 6 Digit RED FND Display |
|
Size :20.0mm(H)×13 mm(W) |
||
|
Min. Division |
×1, ×2, ×5, ×10, ×20, ×50 |
|
|
Max. display value |
999,950 |
|
|
Under Zero value |
"-" (Minus display) |
|
|
Status lamp |
Steady, Zero, Tare, SP1. SP2, SP3, SP4, RTxD |
Green color Condition display Lamp (8pcs) |
|
K e y |
Number, Function Key |
Number Key, Function (16pcs) |
|
- Option |
|
|
Option No.1 |
0~10V (Analogue Output) |
|
Option No.2 |
4~20mA (Analogue Output) |
|
Option No.3 |
RS422/485(Serial interface) |
|
Option No.4 |
BCD Input |
|
Option No.5 |
BCD Output |
※ Serial Interface (RS-232C) or Current Loop is Standard installed with 1 port.
